SMCJ Series TVS Diode

SMCJ Series TVS Diode Specification

Power Supply
Not Required (Passive Component)

Output
Clamped Voltage (as per model selected)

Input
Reverse Standoff Voltage (as per model selected)

Components
Semiconductor Diode

Interface
SMD (Surface Mount Device)

Response Time
< 1ps

Usage
Protection of electronic circuits from voltage spikes

Operating Temperature
-55C to +150C

Display Type
No Display

Features
Unidirectional and Bidirectional Versions; Low Clamping Voltage; Fast Response

Product Type
Surface Mount TVS Diode

Application
Automotive, Industrial, Consumer Electronics, Power Supplies, Telecommunication

Rated Voltage
Varies (e.g. 5V to 440V) depending on model

Supply Voltage
Up to 440V (depending on variant)

Size
DO-214AB (SMCJ) Standard Package

Dimension (L*W*H)
7.11 x 6.22 x 2.62 mm

Function
Transient Voltage Suppression

Color
Black

Weight
Approx. 0.22g

Current Rating
Peak Pulse Current up to 86.3A

Capacity
600 W Peak Pulse Power

Thickness
Approx. 2.62 mm

Frequency
High-speed response (sub-nanosecond range)

Mounting Type
Surface Mount (SMD)

Leakage Current
Typically < 1A

Storage Temperature Range
-55C to +150C

Lead Free/RoHS
Compliant

Body Material
Moulded Plastic

Automotive Grade
Available (on request)

Surge Capability
Supports multiple surge events

Reverse Stand-Off Voltage (V_RWM)
Varies by model (5V440V)

Compliance Standards
IEC 61000-4-2, MIL-STD-750, JESD22-A114

Peak Pulse Power Dissipation (PPP)
600W (10/1000s waveform)

Packaging
Tape & Reel, SMC DO-214AB

Breakdown Voltage
Varies by model

Polarity
Unidirectional or Bidirectional

Clamping Voltage
Varies by model

SMCJ Series TVS Diode Trade Information

Minimum Order Quantity
850 Pieces

Payment Terms
Cash in Advance (CID)

Main Export Market(s)
Asia

Main Domestic Market
All India

About SMCJ Series TVS Diode

Explore the sensation of circuit protection with the praiseworthy SMCJ Series TVS Diode, a hot deal highly in demand by engineers across automotive, industrial, and consumer electronics domains. Boasting impeccable 600W Peak Pulse Power Dissipation with high-speed, sub-nanosecond response, these diodes supply steadfast protection against voltage spikes up to 440V, tailored to your variant. Manufactured to industry standards like IEC 61000-4-2 and MIL-STD-750, they offer unidirectional or bidirectional configurations, RoHS compliance, and surface-mount ease. Secure your applications with a solution that's both robust and reliable-an essential investment in modern surge protection.
